Lower Ball Joints

I am taking off my front end (2wd) to repaint the spindles, drop bracket, and UCA's because a couple of years ago I ran through some salty ice on the freeway and they are rusting in some spots.

While taking off my spindles I noticed that my lower ball joint on the driver's side is bad, so I ordered some new ones for both sides. I removed the clip on top and have been beatin the snot outta the bad one, since it will be replaced anyway, but can't budge it outta the LCA at all.

Do I need to keep at it with bigger hammers, or do I need to replace the entire LCA because they are machine-pressed in there?

Also, I used a pitman arm pulley and the ball joint still wont budge.

ScorchedEarthErotica is offline
Sponsored Links
Advertisement

post #2 of 9 (permalink) Old 01-01-2013, 11:40 PM
Shift_Enthusiast

Join Date: Sep 2011
Location: Canada
Posts: 330
Thanks: 34
Thanked 66 Times in 45 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 0 reviews
What kind of vehicle? assuming 2nd gen, best bet would be to use a balljoint press. Most parts stores will loan/rent the out.

2011 FRONTIER SV 4X4 6SPD CC/LB Knight Armour
Lifted, truetrac, injen, ims, bullydog, skids, HID projectors, WRP underdrive crank pulley, blah, blah blah
speed demon is offline
post #3 of 9 (permalink) Old 01-02-2013, 01:30 PM
Shift_Fanatic

crewmaxxis's Avatar

Join Date: Sep 2008
Location: Vallejo CA
Posts: 723
Thanks: 244
Thanked 199 Times in 142 Posts
Mentioned: 0 Post(s)
Quoted: 3 Post(s)
Feedback Score: 0 reviews
I replaced both of mine recently,

I left the LCA mounted on the truck, used an oversized deep socket (larger than the body of the balljoint) on the bottom used a large sledge hammer on it until it came loose, it helps if you have a flat chisel or drift pin on top of the balljoint for better accuracy,
crewmaxxis is offline
post #4 of 9 (permalink) Old 01-02-2013, 01:36 PM
Super Moderator
Shift_Obsessed
Lifetime Member

Zedbra's Avatar

Join Date: Mar 2007
Location: Squamish, British Columbia
Posts: 8,850
Thanks: 3,100
Thanked 2,588 Times in 1,633 Posts
Mentioned: 0 Post(s)
Quoted: 561 Post(s)
Feedback Score: 5 reviews
and when all else fails, the torch is your friend. Of course, it smells like hell and everyone in the shop will hate you for a long time.
Zedbra is offline
post #5 of 9 (permalink) Old 01-02-2013, 02:51 PM Thread Starter
Shift_Enthusiast

ScorchedEarthErotica's Avatar

Join Date: Nov 2008
Location: San Diego, CA
Posts: 121
Thanks: 1
Thanked 3 Times in 3 Posts
Mentioned: 0 Post(s)
Quoted: 0 Post(s)
Feedback Score: 2 reviews
Send a message via Yahoo to ScorchedEarthErotica
You guys are awesome, thanks. Ima just get a bigger hammer and a few beers and keep at it.

I ran into this problem on a control arm on my friend's '66 Charger. We hammered it, chiseled it, torched it, and swore at it, and eventually just bought a new control arm w/ installed ball joint. I didn't want to have to go that route.

ScorchedEarthErotica is offline
post #6 of 9 (permalink) Old 08-11-2015, 08:40 PM
Shift_Hardcore

pidge's Avatar

Join Date: Jul 2006
Location: Somewhere in Ontario Canada
Posts: 1,162
Thanks: 49
Thanked 60 Times in 52 Posts
Mentioned: 0 Post(s)
Quoted: 4 Post(s)
Feedback Score: 0 reviews
Bring back the dead, old thread I know, but I'm searching for a lower ball joint how to. I did them back in 2010, but I forget how and just wanna cross my t's and dot my i's so to speak before I get started this weekend. I've looked, but can't find one. Any one have any links by chance? Thanks Pidge.
pidge is offline
post #7 of 9 (permalink) Old 08-11-2015, 10:00 PM
Shift_Obsessed

glamisdude's Avatar

Join Date: Apr 2009
Location: Escondido, CA
Posts: 2,602
Thanks: 236
Thanked 772 Times in 455 Posts
Mentioned: 2 Post(s)
Quoted: 147 Post(s)
Garage
Feedback Score: 1 reviews
No how to, but rather than beat the piss out of your arms and mar the press fit surface, do yourself a favor and rent a ball joint press. Makes the install pretty much painless. Not sure in Canada but here I can rent a press for a refundable $55 deposit at my local Autozone. So basically free as long as you don't break it.

Basic how to for ya:

0) pop axle nut cover off and break free axle nut
1) Jack up truck, remove tire
2) disconnect anything attached to spindle (tie rod, UCA, LCA, Axle, brake caliper, rotor, abs line) You can leave the wheel hub mounted in spindle
3) Remove spindle
4) Remove c clip from lower ball joint and soak in penetrating lube.
5) Grab beverage of your choice and let soak in for a bit
6) Get ball joint press out and find which cylinders fit ball joint/control arm mounting best.
7) Use press to remove balljoint: it will feel like nothing is happening at first but keep going until you hear loud bang, it will be mostly free at this point.
Remove one ball joint completely and clean LCA mating surfaces

Installing:
1) Apply a small amount of grease to mating surfaces
2) Reverse removal procedure

DONE! Good luck!

-Chris
2007 KC NISMO-4X Auto Jan 2013, Apr 2015 TOTM Dezert Camper Rev A
2005 KC SE Auto 4x2 Totaled, missed, loved OG Dezert Camper

^Make a pic like this^, Audio Questions? , Torque Specs, Eliminate KC Door Rattle, TITAN SWAP GUIDE, Have a question? PM me
glamisdude is offline
The Following User Says Thank You to glamisdude For This Useful Post:
pidge (08-12-2015)
post #8 of 9 (permalink) Old 08-12-2015, 07:20 AM
Shift_Hardcore

shizzy's Avatar

Join Date: May 2014
Location: Minneapolis, MN
Posts: 1,377
Thanks: 8
Thanked 404 Times in 282 Posts
Mentioned: 0 Post(s)
Quoted: 266 Post(s)
Garage
Feedback Score: 0 reviews
^ ^ ^ ^ ^ This. No reason to Fiddle fark beating on things with a hammer when a specialty tool is available.

2011 Pro-4X CC
shizzy is offline
post #9 of 9 (permalink) Old 08-12-2015, 08:18 PM
Shift_Hardcore

pidge's Avatar

Join Date: Jul 2006
Location: Somewhere in Ontario Canada
Posts: 1,162
Thanks: 49
Thanked 60 Times in 52 Posts
Mentioned: 0 Post(s)
Quoted: 4 Post(s)
Feedback Score: 0 reviews
Thanks Glamis, just went along in my head while I read your reply as to what I did years ago to remove them. Just needed a refresher, guess I'm gettin old. Thanks man for the heads up. We can rent/borrow the joint popper tool up here btw, to be honest I can't remember renting/borrowing it last time, but I must of. Thanks again man. Good stuff.
Pidge.
